It would be nice to have one thread with a whole lot of different pictures of cars on this site to help people when choosing what wheels they would decide to buy.

1. post the pic
2. Wheel brand
3. Wheel size & tire size
4. Backspacing
5. Any clearance issues


·
Registered
Joined
·
2,614 Posts
Re: post up your pictures!

There are quite a few threads already over the years but yes it would be nice to just have that info and pics then make it a sticky in wheels/tires.
A/R Ansen sprints
17x7 with 4" BS and BFG 225/45R17's up front and
17x8 with 4 1/2" BS and Mickey Thompson DR 275/40R17's out back
The front has 2" Hotchkis drop springs. The rear is stock mono leaf.




I've dropped the rear down sense this picture. It had long shackles when I got it, but haven't had a chance to roll her out and shoot another yet. I'd still like a taller tire in the rear, but haven't found a larger 17" drag radial yet.


·
Registered
Joined
·
2,108 Posts
Re: post up your pictures!


Eibach 1" Drop Front, Hotchkis 1.5" Drop Leaf Rear
17" American Racing Torq Thrust ][ Polished 505s
Front: 17x8 (4.75" backspacing) - 5x4.75 pattern (American Racing 505-7863)
Back: 17x9.5 (5.5" backspacing) - 5x4.75 pattern (American Racing TT2 custom)
17" Kumho ECSTA SPT 235/45WR17 Front and 275/40WR17 Rear


·
Registered
Joined
·
1,501 Posts
Re: post up your pictures!



I think that this has been done before, but can't find the thread.

Cragar SS's
15x7 all around
215x60 front
245x60 rear
4.5" back space
BFG T/A's
No clearance or rubbing issues
Original suspension, manual drum brakes all around


·
Retired
Joined
·
26,617 Posts
Re: post up your pictures!

Budnik Anvil 5's​

  • Hotchkis drop springs front (2") and rear (1.5") Koni shocks
  • Front: 17x8 (4.75" backspacing) Nitto 555's 235/45-17
  • Back: 17x9.5 (5.5" backspacing) Nitto 555's 255/45-17
  • 4 wheel manual disc's (C5 front & C4 rear)


"White Wonder"

Car can handle a full trunk and 4 adults with only very slight scrubbing on the inner rear fender wells when going through a steep driveway at an angle to avoid scraping. Future subframe connectors should eliminate this...


·
Registered
Joined
·
1,059 Posts
Re: post up your pictures!





17 Intro Polished Twisted Vistas 17x7F & 17x8R BS 4.75F/5.25R
Yokohama AVS Sport Tires 235/45/07 & 255/40/17

Hotchkis TVS System 2" Front Drop/1.5" Rear Drop
Speedtech Tubular Upper/Lower A Arms

:beers:


·
Registered
Joined
·
1,929 Posts
Ok guys,here's mine...

1969 Z/28
American Racing CL200S
17x8 (4.75" b/s) all-around
235/45's front / 255/45's rear





1970 Z/28
Vintage Wheel Works V40 (straight spokes)
Fronts:
17x8 (4.5" b/s) 245/45's
Rears:
17x9.5 (5.5" b/s) 285/40's







·
Registered
Joined
·
1,929 Posts

·
Registered
Joined
·
374 Posts
Re: post up your pictures!

Fronts are 25x7.50R15LT Hoosiers on 5''x15'' ProStars
Rears are 33''x22.5''x15'' Hoosier Quick Times on 15''x15'' ProStars
Sorry, it's a little dusty.


5" backspace on the rears if I remember right. 36'' axle flange to axle flange


·
Registered
Joined
·
1,929 Posts
Re: post up your pictures!

Fronts are 25x7.50R15LT Hoosiers on 5''x15'' ProStars
Rears are 33''x22.5''x15'' Hoosier Quick Times on 15''x15'' ProStars
Sorry, it's a little dusty.
Cars look sick dude!:yes:
I tried opening the pictures here at work but they were blocked by websense because of "adult content"!Figures,those wheels look like straight porn to me...:yes:


·
Registered
Joined
·
374 Posts
Re: post up your pictures!

HUMMMM Donno' how to undo that deal, cuz' I don't know what I did to activate it. :noway: Kids shouldn't be LQQKin' at tires like that anyway.:D


·
Registered
Joined
·
1,929 Posts
Re: post up your pictures!

HUMMMM Donno' how to undo that deal, cuz' I don't know what I did to activate it. :noway: Kids shouldn't be LQQKin' at tires like that anyway.:D
No prob...I'll just check 'em out when I get home.:thumbsup:


·
Registered
Joined
·
332 Posts
Re: post up your pictures!

Here's another one.
